• Available in "T" or "L" port configurations
• 1/4”-1 1/2”Full Port,1 1/2”-2” Reduce Port
• ISO 5211 Mounting Pad
• Live-loaded stem packing
• Blow-out-proof stem
• Investment cast Body and End Caps
• Anti-Static Device for Ball-Stem –Body
• Pressure Blance Hole in Ball Slot
• Locking Device Spring Handle Available
• Reduces number of valves required in piping system
• Full port construction improves flow characteristics
• Standard mounting pad for ease of automation
• Live-loaded stem packing improves cycle life
• Balanced 4-seat construction provides for positive shut-off


• Operating Temperature Range: -20℃ to 190℃
• Maximum Working Pressure:
  1000 WOG
• Working Medium: Water, Oil, Gas, Acid, etc
• End Type: NPT to ASME B1.20.1,BSPT to DIN 2999,BSP to DIN259
• Design:ASME B16.34
• Inspection&Testing to API 598,EN12266

2) PRODUCT DESIGN DRAWING:
