• Full Port Design
  Full port construction improves flow characteristics for greater process efficiencies
• Blow-Out-Proof Stem
  Stem is bottom loaded to prevent removal when valve is in service
• Locking Device
  Enables plant personnel to secure valve in open or closed position when manually operated
• Live-Loaded Stem Packing
  Provides constant load on the stem seal and extends service life
• Corrosion Resistant
  Made of 316 stainless steel (A351 Gr. CF8M) for greater chemical resistance and longer service life
• ISO 5211 - Mount Pad
• Anti-Static Device for Ball-Stem-Body
• Pressure Blance Hole in Ball Slot
• 2 Belleville Washer to Self-adjust Packing
• Fire safety Design


• Temperature Range: -20℃ to 190℃
• Maximum Working Pressure:
  ANSI 150
• Working Medium: Water, Oil, Gas, Acid, etc
• Design: ANSI/ASME B16.34,EN 12516-1
• Inspection&Testing:API 598,EN 12266
• Length to ANSI B16.10
  Flange connection to ANSI B16.5

2) PRODUCT DESIGN DRAWING:

3) PARTS MATERIAL:



4) SIZES:
